ChromoSphere™-T Certified Size Standards
Actual product may vary
THERMO SCI PARTICLE TECHNOLOGY

ChromoSphere™-T Certified Size Standards

Achieve high visual contrast with Thermo Scientific™ ChromoSphere™-T Certified Size Standards, colored polymer microspheres with NIST™-traceable diameters.
Have Questions?
Change viewbuttonViewtableView
Catalog NumberDiameter (Metric)ColorSize Distribution
09980126500 μmBlacks = 22µm, 4.5% CV
09980120200 μmBlacks = 10µm, 5.0% CV
09980121300 μmReds = 11µm, 3.5% CV
Catalog number 09980126
Price (USD)
-
Diameter (Metric):
500 μm
Color:
Black
Size Distribution:
s = 22µm, 4.5% CV

Achieve high visual contrast with Thermo Scientific™ ChromoSphere™-T Certified Size Standards, colored polymer microspheres with NIST™-traceable diameters. These reference and calibration materials are used in the testing of filtration systems, vial cleaning evaluations, contamination control studies and calibration of injection devices.

ChromoSphere-T Size Standards were developed for use as reference or calibration materials in applications where a high visual contrast is desired. The product line consists of a large assortment of uniform particle sizes between 50 and 500 microns in either red or black color.
  • Internally dyed with deeply colored red or black dyes, resulting in very high contrast and visibility relative to most background materials
  • Mean diameters traceable to the standard meter through the National Institute of Standards and Technology (NIST)
  • Calibrated by optical microscopy
  • Made from cross-linked polystyrene divinylbenzene (PS-DVB) copolymer
  • Available as dry powders
  • Easily dispersed in aqueous media with the aid of a small amount of surfactant or in lower alcohols, such as methanol or ethanol
  • Minimal dye extraction when particles are suspended in pure alcohols
Note:
  • Other organic solvents, such as ethers or chlorinated hydrocarbons, should be avoided because they will swell the particles and completely extract the dye.
Specifications
Concentration100% solids
Size Distributions = 22µm, 4.5% CV
Quantity1 g
Product TypeSize Standard Particles
Particle Density1.05g/cm³
ContentsDry dyed polystyrene (DVB) microspheres
StabilityProduct stable for a minimum of 24 months
DescriptionDesigned for use as reference or calibration materials in applications where high contrast is required.
For Use With (Application)Cleaning Evaluation, High Contrast Reference and Calibration
Certifications/ComplianceCertificate of Calibration and Traceability to NIST
Diameter (Metric)500 μm
AdditiveMay contain trace amount of dispersant
ColorBlack
IncludesCertificate of Calibration and Traceability to NIST
MaterialPolystyrene Divinylbenzene (PS-DVB)
Refractive Index1.59 at 589nm (25°C)
Unit SizeEA
Contents & Storage
Store at room temperature in a dry area. Store upright and keep bottle tightly sealed. Respiratory protection from dust is recommended.
